Below are some examples of our project graphics:


Bridgepoint (Chapel Hill)

Mixed-use (retail, office, and residential)

Conditional Rezoning / Special Use Permit



Lloyd Farm (Carrboro)

Mixed-use (retail, office, clinic, and senior-living residential)

Concept Plan / Conditional Rezoning / Conditional Use Permit (in progress)



Mid-Town Square (Cary)

Downtown mixed-use infill and adaptive reuse (retail, restaurants, office, and conversion of warehouse space to a brewery/bar)

Concept Plan / Landscape Plan



AutoZone (Chapel Hill)

Infill Redevelopment (commercial)

Conditional Rezoning / Special Use Permit



Walgreens (E. Franklin & S. Estes, Chapel Hill)

Silver LEED Infill Redevelopment  (gas station / car wash -> pharmacy)

Special Use Permit Modification



Waterstone (Hillsborough)

Mixed-use (community college, hospital, retail, office, multi-family & single-family residential)

Master Plan / Rezoning / Subdivision Plat



Eaton's Crossing (Lake Gaston, Warren County)

Gated Resort (single-family & multi-family residential with boathouses & lakefront pedestrian trails)

Rezoning / Planned Unit Development Site Plan / Subdivision Plat


Haley Property - Site Plan 3-20-06.jpg

The Landing at Lake Michael (Mebane)

Subdivision (single-family and patio-home lots with clubhouse/pool and pedestrian trails)

Rezoning / Special Use Permit / Preliminary Subdivision Plat
